Specifications
-
Measurements120 x 61 x 14 mm / 4.72 x 2.4 x 0.55 "
-
Weight48 g / 1.69 oz
-
Bezel material:Plastic
-
What's in the box?Suunto M-3 G Compass, lanyard, quick release, Quick Guide
-
Country of manufactureFI
- Fast globally balanced needle with jewel bearing
- 20 degrees tilt margin for easier readings
- Adjustable declination correction
- Liquid filled capsule for stable operation
- Clinometer
- Luminescent markings for working in low light
- Metric and Imperial UTM scales
- Baseplate with magnifying lens
- Detachable snap-lock lanyard with wristlock. Easy to detach for working with the map
- Suunto limited lifetime warranty
- Made in Finland
- NSN: 6695-58-000-9441
Technical specifications
GENERAL
-
Bezel material:Plastic
-
Metric scalescm, 1:25 000 km UTM, 1:50 000 km UTM
-
Imperial scalesinch, 1:24 000 mi, 1:24 000 km UTM, 1:50 000 km UTM
-
Declination correctionadjustable
-
Weight48 g / 1.69 oz
-
Water resistanceinsensitive to water pressure
-
Battery typeno battery required
-
Luminous markingsbezel, orienting markings and direction of travel
-
Attachmentlanyard
COMPASS
-
Direction scaledegrees
-
NeedleSuunto global needle
-
Globally balanced✔
-
Liquid filled and jewel bearing✔
-
Bearing lock with orienting indicator✔
-
Compass accuracy2°
-
Compass resolution2°
PHYSICAL SPECIFICATIONS
-
Operating temperature-30° C to +60° C / -22° F to +140° F
-
Storage temperature-30° C to +60° C / -22° F to +140° F
OUTDOOR FUNCTIONS
GPS TRACKING & NAVIGATION
-
Magnifying lens✔
CLINOMETER
-
Clinometer✔
-
Liquid filled✔
-
Clinometer scales0 ± 90°
-
Inlcination accuracy2°
-
Inclination resolution2°
